T & S MTP® / MPO IP waterproof jumper is used for outdoor laying. It has the characteristics of high-temperature resistance and high strength. It is suitable for all kinds of harsh outdoor environments. It meets the IP67 / 68 environmental sealing grade and meets the ec60603-7 interface standard. There are SM / om1 / om2 / OM3 / OM4 / om5 optical fiber models, TIA568 type A, B, C standard polarity and customized product polarity, male and female head, conventional and low loss specifications.
Performance | Standard | Low loss | ||||
Connector | mode | End face | IL (dB) | IL (dB) | IL (dB) | IL (dB) |
MPO/MTP | SM | 12F/APC | ≤0.75 | ≥60 | ≤0.35 | ≥60 |
24F/APC | ≤0.75 | ≥60 | ≤0.35 | ≥60 | ||
MM | 12F/APC | ≤0.50 | ≥20 | ≤0.35 | ≥20 | |
24F/APC | ≤0.50 | ≥20 | ≤0.35 | ≥20 | ||
Test wavelength: SM@1310/1550nm, MM@850/1300nm
Cable count | Out sheath Diameter （mm) | Weight （KG) | Minimum allowable Tensile Strength (N) | minimum allowable Crush Load （N/100mm) | Minimum Bending Radius (MM) | Storage temperature (℃) | |||
short term | long term | short term | long term | short term | long term | ||||
8/12/24 | 7.0±0.3 | 45 | 1000 | 600 | 3000 | 1000 | 20D | 10D | -40 ~~ +70 |
